FLIR CM65 True RMS 600 A Solar Clamp Meter
100 of 200 Sold
Viewing This Product
Free Shipping
4 Great reasons to buy from us:
Specifications
Overview
- Backlight LCD
- Yes
- Jaw Opening
- 30 mm Max
- Size [L × W × H]
- 251 × 86 × 41 mm (9.9 × 3.4 ×1.6 in)
- Warranty
- Limited 3 years
Compliance & Certifications
- Certifications
- UL,CE, FCC
Connections & Communications
- Connectivity
- Bluetooth®
Environmental
- Operating Temperature
- 32 °F to 140 °F (0 °C to 60 °C)
- Temperature
- -40 to 752°F (-40 to 400 °C)
Measurement & Analysis
- AC Current
- Range 60.00, 600.0 A / Basic Accuracy ±1.5%
- AC Voltage (Digital Low Pass Filter-VFD)
- Range 60.00, 600.0, 1000 V / Basic Accuracy ±1%
- AC/DC Voltage
- [AC] Range 60.00, 600.0, 1000 V / Basic Accuracy ±0.7% [DC] Range 60.00, 600.0, 1000 V / Basic Accuracy ±1% .. [mV] Range 60.00, 600.0 mV / Basic Accuracy ±1%
- Category Rating
- CAT IV-600 V, CAT III-1000 V
- Clamp-On DC Current
- Range 60.00, 600.0 A / Basic Accuracy ±1.5%
- Continuity
- Between 30 and 480 ?. Beeper can be on or off
- Diode
- Range 3 V / Basic Accuracy ±0.9%
- Frequency
- Range 10 Hz to 50 kHz (60.00 mV, 600.0 mV, 60.00 V) / Basic Accuracy ±0.03% Range 10 Hz to 1 kHz (600.0 V, 1000 V) / Basic Accuracy ±0.03% Range 10 Hz to 400 Hz (VFD 600.0 V, 1000 V) / Basic Accuracy ±0.03% Range 50 Hz to 400 Hz (60.00 A, 600.0 A) / Basic Accuracy ±0.03%
- LoZ Mode AC Voltage
- Range 60.0, 600.0, 1000 V / Basic Accuracy ±2%
- LoZ Mode DC Voltage
- Range 60.00, 600.0, 1000 V / Basic Accuracy ±2%
- Resistance
- Range 600.0, 6.000 K? / Basic Accuracy ±1%
Meter Data
- Auto Power Off
- 10 minutes
- Display
- 3-5/6 digits 6000 counts
- Recording
- Automatically log readings (8 GB internal memory)
Power
- Battery
- 3 x AA
Loaded with the features you need
-
Optimized for solar installers
Get accurate testing capabilities like True RMS, LoZ, and Millivolt modes to get the job done right the first time.
-
Designed to help you work faster & smarter
This full-featured clamp meter with solar industry-standard MC4 connectors saves time and pinpoints trouble quickly.
-
The right tech to simplify your workflow
The FLIR CM65 is packed with tech tools to help you validate testing, document readings and share results with crews and customers.
